Ask any experienced manufacturer what separates a smooth first production run from a painful one, and the answer is almost always the same: the tech pack. Not the logo, not the fabric, not even the budget — the document that tells the factory, in precise and unambiguous terms, exactly what to build.
A tech pack is easy to underestimate, especially for a first-time brand founder. It’s tempting to think a sketch, a reference photo, and a quick description are enough. In practice, that’s usually the point where costly sample revisions and weeks of delay quietly begin.
WHAT A TECH PACK ACTUALLY IS
A tech pack (short for “technical package”) is a document that translates a design idea into the technical specifications a factory can actually build from. It functions the way an architectural blueprint does for a construction crew — a house can’t be built from a watercolor of the exterior, and a garment can’t be manufactured consistently from a flat sketch and a fabric swatch alone.
It’s also the communication layer between everyone involved: the designer, the pattern maker, the factory floor, and quality control. When something in the finished product doesn’t match expectations, the tech pack is usually the first place to check — either a spec was missing, or it wasn’t followed.
WHY IT’S NON-NEGOTIABLE
Most manufacturers won’t begin sampling or issue a firm quote without one, and for good reason. Without a tech pack, a factory is forced to guess at measurements, fabric weight, seam types, and finishing — and every guess is a chance for the sample to come back wrong.
The cost of skipping this step tends to show up later, and bigger than expected. A single missing tolerance on a measurement, or a vague trim description like “black zipper” instead of a specific size and brand reference, can turn one sampling round into three. Multiply that by shipping time and factory scheduling, and a shortcut at the design stage can add weeks — sometimes months — to a launch timeline.
THE ESSENTIAL CHECKLIST: WHAT A STANDARD TECH PACK MUST INCLUDE
Formats vary between brands and factories, but a production-ready tech pack consistently includes the following sections. Treat these as the non-negotiable core — everything else is a bonus.
- Technical flat sketches Black-and-white, two-dimensional line drawings of the garment — front, back, and side views at minimum, with interior views for anything structurally unusual. These are not design illustrations; solid lines represent seams, dashed lines represent stitching, and every construction detail worth noting (pockets, plackets, cuffs) should be called out directly on the sketch.
- Bill of Materials (BOM) The master list of every fabric, trim, and component that goes into the garment — main fabric, ribbing, thread, labels, zippers, buttons, packaging materials. Vague descriptions cause real problems here: “nylon zipper” isn’t a specification, but “YKK #5 vislon zipper, navy blue, antique brass puller” is. The BOM is also what allows a factory to quote accurately and source consistently, order after order.
- Measurement spec sheet (Point of Measure / POM) A chart of every key measurement — chest width, body length, sleeve length, and so on — each with a tolerance range (commonly ±1 cm for most basics). Measurements without tolerances are a common source of disputes: a factory may reject a sample over a 0.3 cm deviation that was never actually out of spec, simply because no acceptable range was defined.
- Construction details The “how,” not just the “what.” This section documents seam types, stitch types, stitch density (stitches per inch), seam finishes, and assembly sequence — details that are invisible in the finished garment but directly affect its durability, drape, and cost.
- Colorways and labeling Every colorway the style will be produced in, referenced against a standardized system like Pantone rather than a screen-dependent color name. This section also covers brand labels, care labels, and their exact placement.
- Grading rules If the garment will be produced across a size range, grading rules define exactly how each measurement changes from one size to the next — the difference that keeps a size Large actually proportional to a size Small, rather than just “bigger.”
- Packaging and shipping instructions How the finished garment should be folded, tagged, bagged, and boxed. This section is easy to skip and easy to regret skipping — packaging errors are a common, avoidable source of returns and client complaints.
- Reference images and fit references Photos of a similar existing garment, close-up detail shots, or reference images that clarify anything difficult to fully capture in a sketch or written spec.
A GOOD HABIT: TREAT IT AS A LIVING DOCUMENT Whenever a design changes — even a small one — the tech pack should be updated and re-dated immediately. A factory working from an outdated version is one of the most common, and most avoidable, causes of a sample coming back wrong.
CASE STUDY: A SIMPLE T-SHIRT WITH A FRONT AND SLEEVE PRINT
To make this concrete, here’s what a tech pack actually looks like for a genuinely simple product: a basic crewneck t-shirt with a small front chest print and a small print on the left sleeve.
Even a “simple” garment like this has enough moving parts that skipping documentation causes real problems — so here’s how each section plays out in practice.
Technical flats Front and back flat sketches show the garment silhouette: crew neckline, set-in sleeves, straight hem. Two callouts are marked directly on the front sketch: the chest print position and the sleeve print position, each referencing a placement measurement rather than a vague description like “small logo on the chest.”
Bill of materials
- Body fabric: 180 gsm combed cotton jersey
- Neck binding: self-fabric rib, 1×1 rib knit
- Thread: polyester core-spun, color-matched to garment
- Main label: woven brand label, center back neck
- Care label: printed, side seam
- Print method: water-based screen print, one color
Measurement spec sheet (size Medium, example)
- Chest width (1″ below armhole): 51 cm, tolerance ±1 cm
- Body length (HPS to hem): 71 cm, tolerance ±1.5 cm
- Sleeve length (shoulder seam to hem): 20 cm, tolerance ±0.7 cm
Print placement — this is the detail that most “simple” t-shirt tech packs get wrong
- Front chest print: centered horizontally, 8 cm below High Point Shoulder (HPS), print width not exceeding 9 cm
- Sleeve print: centered on left sleeve, 6 cm above sleeve hem, print width not exceeding 5 cm
- Both placements given a tolerance of ±0.5 cm — enough precision that two production runs, months apart, come out matching
Construction details
- Shoulder seams: overlock stitch, reinforced with taping
- Sleeve and side seams: overlock, single pass
- Hem and sleeve hem: double-needle topstitch, 2 cm depth
- Neck binding: 1 cm finished width, edge-stitched
Colorways and labeling Two colorways specified: Black body with white ink, and White body with black ink, both referenced against a Pantone Textile Paper eXtended (TPX) code rather than a screen color.
Grading A basic grading rule applied across S–XL: chest width increasing by 5 cm per size, body length by 2 cm per size, sleeve length by 1 cm per size — with the print placement measurements from High Point Shoulder held constant across all sizes, so the print doesn’t visually shift position between a Small and an XL.
Packaging Each unit folded flat, individually polybagged, with the care label visible without opening the bag, and barcoded hang tags attached via a plastic tag pin.
That’s the full document for what looks, at a glance, like the simplest possible garment. None of it is excessive — every section exists because leaving it out has, in practice, caused a real production mistake somewhere.
THE BOTTOM LINE
A tech pack isn’t paperwork for its own sake — it’s the single document most responsible for whether a sample matches what you actually imagined. Even a straightforward product like a basic t-shirt with two small prints has enough detail in it to go wrong without one. Building the habit of documenting a design properly before it reaches a factory is, consistently, the cheapest step in the entire production process.
=====================================================
Q&A
What is a tech pack in fashion manufacturing? A tech pack is a detailed document that translates a garment design into the technical specifications a factory needs to manufacture it — including flat sketches, measurements, materials, construction details, and labeling instructions.
Why do I need a tech pack before contacting a manufacturer? Most manufacturers won’t begin sampling or provide a firm quote without one, since it removes the guesswork around fit, materials, and construction. Skipping it typically leads to more sampling rounds, longer timelines, and higher costs than preparing one upfront.
What are the essential sections of a tech pack? At minimum: technical flat sketches, a bill of materials, a measurement spec sheet with tolerances, construction details, colorways with labeling information, grading rules for multi-size production, and packaging instructions.
What is a Point of Measure (POM) in a tech pack? A POM is a specific measurement point on a garment — such as chest width or sleeve length — listed with an acceptable tolerance range, so both the brand and the factory have a shared, objective standard for what counts as an accurate sample.
Do I need a full tech pack for a simple product like a basic t-shirt? Yes. Even simple garments involve enough detail — print placement, seam types, grading, labeling — that skipping a proper tech pack is a common source of avoidable sample errors, as shown in the t-shirt case study above.
